Compression Ratio |
Adjustable from 1:1 to 20:1 |
Maximum Compressor Gain |
+50dBr |
Attack Speed |
Adjustable from 3.2ms to 50ms |
Double Back Gain |
Fully "off" to +34dB |
Battery Life |
100 Hours with a premium alkaline battery |
Power Source |
9V battery or external 9VDC regulated wall transformer, enter pin negative. 5mA current drain |
Input Impedance |
1 M ohm (1000K ohms) |
Output Impedance |
2.75K ohms maximum |
Output Clipping Level |
7V Peak-to-Peak |
Distortion |
Less than 0.3% at 300mV RMS output at 1 kHz |
Noise referred to Input |
-102dBV unweighted, 400Hz - 20kHz, input shorted |
Type of Circuitry |
True bypass, class A |
Compressor type |
Voltage Controlled Amplifier (VCA) |
Dimensions |
4.75" wide X 5.0" tall X 2.3" high |
Weight |
1.5 lbs. |
Chassis Materi |
16 gauge steel |
Price |
31,500 yen (Include Tax) |
